Appendices Apx. C Pin Assignments
Qosmio F40/F45 Maintenance Manual C-9
C.16 CN18 Wireless LAN Module Connector (52-Pin)
Table C-16 Wireless LAN Module Connector Pin Assignments (52-Pin)
Pin No. Signal Name I/O Pin No. Signal Name I/O
1 PCIE_WAKE# I/O 2 +V3S O
3 CH_DATA I/O 4 DGND -
5 CH_CLK I/O 6 +V1.5S O
7 CLKREQ_R_MINI2# I 8 LPC_3S_FRAME# O
9 DGND - 10 LPC_3S_AD(3) O
11 CLK_R_PCIE_MINI2# O 12 LPC_3S_AD(2) O
13 CLK_R_PCIE_MINI2 O 14 LPC_3S_AD(1) O
15 DGND - 16 LPC_3S_AD(0) O
17 BUF_PLT_RST# O 18 DGND -
19 CLK_R3S_MINICARD2 O 20 WXMIT_OFF# O
21 DGND - 22 BUF_PLT_RST# O
23 PCIE_C_RXN2 I 24 +V3A_WLAN O
25 PCIE_C_RXP2 I 26 DGND -
27 DGND - 28 +V1.5S O
29 DGND - 30 ICH_3A_ALERT_CLK I/O
31 PCIE_C_TXN2 O 32 ICH_3A_ALERT_DAT I/O
33 PCIE_C_TXP2 O 34 DGND -
35 DGND - 36 - -
37 - - 38 - -
39 - - 40 DGND -
41 - - 42 - -
43 - - 44 WLAN_LED# I
45 - - 46 - -
47 - - 48 +V1.5S O
49 - - 50 DGND -
51 - - 52 +V3S O
C.17 CN19 Audio Board Connector (20-Pin)
Table C-17 Audio Board Connector Pin Assignments (20-Pin)
Pin No. Signal Name I/O Pin No. Signal Name I/O
1 +V5S O 2 +V5S O
3 SPDIF O 4 DGND -
To Next Page
