Appendices Apx. C Pin Assignments
C-12 Qosmio F40/F45 Maintenance Manual
C.24 CN807 FAN Connector (3-Pin)
Table C-24 FAN Connector Pin Assignments (3-Pin)
Pin No. Signal Name I/O Pin No. Signal Name I/O
1 N$814474 O 2 DGND -
3 FAN_TACH1 I
C.25 CN808 DDR2 DIMM0 Socket (200-Pin)
Table C-25 DDR2 DIMM0 Socket Pin Assignments (200-Pin)
Pin No. Signal Name I/O Pin No. Signal Name I/O
1 M_VREF O 2 DGND -
3 DGND - 4 M_DATA(4) I/O
5 M_DATA(0) I/O 6 M_DATA(5) I/O
7 M_DATA(1) I/O 8 DGND -
9 DGND - 10 M_DM(0) I
11 M_DQS#(0) O 12 DGND -
13 M_DQS(0) I/O 14 M_DATA(6) I/O
15 DGND - 16 M_DATA(7) I/O
17 M_DATA(2) I/O 18 DGND -
19 M_DATA(3) I/O 20 M_DATA(12) I/O
21 DGND - 22 M_DATA(13) I/O
23 M_DATA(8) I/O 24 DGND -
25 M_DATA(9) I/O 26 M_DM(1) O
27 DGND - 28 DGND -
29 M_DQS#(1) I/O 30 M_CLK_DDR0 I/O
31 M_DQS(1) I/O 32 M_CLK_DDR0# I/O
33 DGND - 34 DGND -
35 M_DATA(10) I/O 36 M_DATA(14) I/O
37 M_DATA(11) I/O 38 M_DATA(15) I/O
39 DGND - 40 DGND -
41 DGND - 42 DGND -
43 M_DATA(16) I/O 44 M_DATA(20) I/O
45 M_DATA(17) I/O 46 M_DATA(21) I/O
47 DGND - 48 DGND -
49 M_DQS#(2) I/O 50 PM_EXTTS#0 I
51 M_DQS(2) O 52 M_DM(2) O
