Toshiba Qosmio F40

Appendices Apx. C Pin Assignments
C-22 Qosmio F40/F45 Maintenance Manual
1 1394_L_TPB0N I/O 2 1394_L_TPB0P I/O
3 1394_L_TPA0N I/O 4 1394_L_TPA0P I/O
C.34 CN818 SATA HDD-1 Connector (22-Pin)
Table C-34 SATA HDD-1 Connector Pin Assignments (22-Pin)
Pin No. Signal Name I/O Pin No. Signal Name I/O
1 DGND - 2 SATA_C_TXP0 O
3 SATA_C_TXN0 O 4 DGND -
5 SATA_RXN0 I 6 SATA_C_RXP0 I
7 DGND - 8 - -
9 - - 10 - -
11 DGND - 12 DGND -
13 DGND - 14 +V5S O
15 +V5S O 16 +V5S O
17 DGND - 18 - -
19 DGND - 20 - -
21 - - 22 - -
C.35 CN819 Battery Pack Connector (9-Pin)
Table C-35 Battery Pack Connector Pin Assignments (9-Pin)
Pin No. Signal Name I/O Pin No. Signal Name I/O
1 N$1040717 - 2 N$1040717 -
3 N$1188781 I 4 DGND -
5 N$1003370 I 6 BATT_DATA I/O
7 BATT_CLK I/O 8 DGND -
9 DGND -
C.36 CN1000 LED Board Connector (28-Pin)
Table C-36 LED Board Connector Pin Assignments (28-Pin)
Pin No. Signal Name I/O Pin No. Signal Name I/O
1 +V5A O 2 +V5S O
3 +V3LA O 4 +V3A O
5 +V3 O 6 +V3S O
