Appendices Apx. C Pin Assignments
Qosmio F40/F45 Maintenance Manual C-27
C.39 CN3000 Touch Pad Board to Module Connector (12-Pin)
Table C-39 Touch Pad Board to Module Connector Pin Assignments (12-Pin)
Pin No. Signal Name I/O Pin No. Signal Name I/O
1 LEFT_TP O 2 - -
3 - - 4 - -
5 - - 6 RIGHT_TP O
7 GND_TP - 8 GND_TP -
9 IM_CLK_5_F I/O 10 IM_DAT_5_FP I/O
11 N$1109478 - 12 N$1109478 -
C.40 CN3001 USB Port8 IO/B to M/B Connector (16-Pin)
Table C-40 USB Port8 IO/B to M/B Connector Pin Assignments (16-Pin)
Pin No. Signal Name I/O Pin No. Signal Name I/O
1 GND_TP - 2 USB_P8+_FP O
3 USB_P8-_FP O 4 GND_TP -
5 IM_CLK_5_FP O 6 IM_DAT_5_FP O
7 GND_TP - 8 - -
9 +V3S_FP O 10 +V3S_FP O
11 +V3S_FP O 12 +V3S_FP O
13 - - 14 GND_TP -
15 GND_TP - 16 GND_TP -
C.41 CN4000 TV Tuner Connector (8-Pin)
Table C-41 TV Tuner Connector Pin Assignments (8-Pin)
Pin No. Signal Name I/O Pin No. Signal Name I/O
1 TVGND - 2 EXCVB1-PXP O
3 TVGND - 4 EXINL-PXP O
5 - - 6 EXINR-PXP O
7 TVGND - 8 TVGND -
C.42 CN4001 Audio Board to M/B Connector (20-Pin)
Table C-42 Audio Board to M/B Connector Pin Assignments (20-Pin)
