Appendices Apx. C Pin Assignments
Qosmio F40/F45 Maintenance Manual C-25
115 XBCLKM-P3P I/O 116 DGND -
117 DGND - 118 DGND -
119 DGND - 120 DGND -
121 BCPWON-P3P I/O 122 - -
123 +V5S O 124 - -
C.38 CN2009 TV Tuner Slave Connector (124-Pin)
Table C-38 TV Tuner Slave Connector Pin Assignments (124-Pin)
Pin No. Signal Name I/O Pin No. Signal Name I/O
1 TSA-P5V O 2 TSA-P5V O
3 TSA-P5V O 4 TSA-P5V O
5 TSA-P5V O 6 TSA-P5V O
7 - - 8 - -
9 TSA_GND - 10 TSA_GND -
11 TSA_GND - 12 TSA_GND -
13 TSA_GND - 14 TSA_GND -
15 DGND - 16 - -
17 PCI_3S_INTE# I 18 TSA-P5V O
19 TS-P3V O 20 PCI_3S_INTF# I
21 X33TU4-P3P O 22 N$1187079 -
23 DGND - 24 - -
25 X33TU3-P3P O 26 N$1106904 -
27 DGND - 28 TS-P3V O
29 PCI_3S_REQ#(3) I 30 PCI_3S_GNT#(3) I/O
31 TS-P3V O 32 DGND -
33 PCI_3S_AD(31) I/O 34 - -
35 /PCI_3S_AD(29) I/O 36 PCI_3S_GNT#(1) I/O
37 DGND - 38 PCI_3S_AD(30) I/O
39 PCI_3S_AD(27) I/O 40 TS-P3V O
41 PCI_3S_AD(25) I/O 42 PCI_3S_AD(28) I/O
43 PCI_3S_REQ#(1) I 44 PCI_3S_AD(26) I/O
45 PCI_3S_CBE#(3) I/O 46 PCI_3S_AD(24) I/O
47 PCI_3S_AD(23) I/O 48 N$1106878 -
49 DGND - 50 DGND -
51 PCI_3S_AD(21) I/O 52 PCI_3S_AD(22) I/O
