4 Replacement Procedures 4.16
Broadcom Card
Installing the Broadcom Card
Install the Broadcom card according to the following procedures and Figure 4-31.
1. Insert the Broadcom card into the connector an angle of 45 degrees.
2. Press down on the Broadcom card to secure it with two M2x2 white bind screws.
CAUTION: Do not touch the connectors on the Broadcom card and in the computer
with your bare hands. Broadcom card can fail if they are contaminated with sweat,
natural oils, etc. from your hands.
4-56 Qosmio F40/F45 Maintenance Manual
