Appendices Apx. C Pin Assignments
Qosmio F40/F45 Maintenance Manual C-23
7 DGND - 8 DCIN_BLED# O
9 PWR_BUF_BLED# O 10 PWR_BUF_OLED# O
11 BAT0_BLED# O 12 BAT0_OLED# O
13 HDD_LED# O 14 ODD_LED# O
15 LED_6IN1 O 16 WLON# O
17 BTIFON# O 18 REC_LED O
19 RESERVE_LED# O 20 DGND -
21 +V5LA O 22 +V5LA O
23 - - 24 CIR_OUT O
25 N$1184408 - 26 L_CIR_RX1 -
27 DGND - 28 DGND -
C.37 CN2003 TV Tuner Master Connector (124-Pin)
Table C-37 TV Tuner Master Connector Pin Assignments (124-Pin)
Pin No. Signal Name I/O Pin No. Signal Name I/O
1 TMA-P5V O 2 TMA-P5V O
3 TMA-P5V O 4 TMA-P5V O
5 TMA-P5V O 6 TMA-P5V O
7 - - 8 - -
9 TMA_GND - 10 TMA_GND -
11 TMA_GND - 12 TMA_GND -
13 TMA_GND - 14 TMA_GND -
15 DGND - 16 - -
17 PCI_3S_INTE# I 18 TMA-P5V O
19 TM-P3V O 20 PCI_3S_INTD# I
21 X33TU2-P3P O 22 N$1051338 -
23 DGND - 24 - -
25 X33TU1-P3P O 26 N$1051347 -
27 DGND - 28 TM-P3V O
29 PCI_3S_REQ#(0) I 30 PCI_3S_GNT#(0) I/O
31 TM-P3V O 32 DGND -
33 PCI_3S_AD(31) I/O 34 - -
35 /PCI_3S_AD(29) I/O 36 PCI_3S_GNT#(1) I/O
37 DGND - 38 PCI_3S_AD(30) I/O
39 PCI_3S_AD(27) I/O 40 TM-P3V O
