Appendices Apx. C Pin Assignments

C-20 Qosmio F40/F45 Maintenance Manual

Pin No. Signal Name I/O Pin No. Signal Name I/O

1 PCIE_WAKE# I/O 2 +V3S O

3 - - 4 DGND -

5 - - 6 +V1.5S O

7 - - 8 - -

9 DGND - 10 - -

11 CLK_R_PCIE_MINI3# O 12 - -

13 CLK_R_PCIE_MINI3 O 14 - -

15 DGND - 16 - -

17 - - 18 DGND -

19 - - 20 - -

21 DGND - 22 BUF_PLT_RST# O

23 PCIE_C_RXN4 I 24 +V3A O

25 PCIE_C_RXP4 I 26 DGND -

27 DGND - 28 +V1.5S O

29 DGND - 30 ICH_3A_ALERT_CLK I/O

31 PCIE_C_TXN4 O 32 ICH_3A_ALERT_DAT I/O

33 PCIE_C_TXP4 O 34 DGND -

35 DGND - 36 USB_P5- I/O

37 DGND - 38 USB_P5+ I/O

39 +V3S O 40 DGND -

41 +V3S O 42 - -

43 DGND I/O 44 - -

45 - - 46 - -

47 - - 48 +V1.5S O

49 - - 50 DGND -

51 - - 52 +V3S O

C.31 CN814 BCAS Card Connector (10-Pin)

Table C-31 BCAS Cad Connector Pin Assignments (10-Pin)

Pin No. Signal Name I/O Pin No. Signal Name I/O

1 BCASF-P5V O 2 BCRST-P5N O

3 XBCCLK-P5P O 4 - -

5 DGND - 6 - -

7 BCIO-P5P O 8 - -
