Apx. A Handling the LCD Module Appendices
Appendix A
Appendix A Handling the LCD Module
Precautions for handling the LCD module
The LCD module can be easily damaged during assembly or disassembly. Observe the
following precautions when handling the LCD module:
1. When installing the LCD module in the LCD cover, be sure to seat it so that it is
properly aligned and maximum visibility of the display is maintained.
2. Be careful to align the four holes at the right side and left side of the LCD module
with the corresponding holes in the LCD cover before securing the module with four
screws. Do not force the module into place, because stress can affect its performance.
Also, the panel’s polarized surface is easily scarred, so be carefully when handling it.
Qosmio F40/F45 Maintenance Manual A-1
