Appendices Apx. C Pin Assignments
Qosmio F40/F45 Maintenance Manual C-29
15 LED_6IN1_DB O 16 WLON#_DB O
17 BTIFON#_DB O 18 REC_LED_DB O
19 RESERVE_LED#_DB O 20 LED_GROUND -
21 +V5LA_LB O 22 +V5LA_LB O
23 - - 24 CIR_OUT_LB O
25 N$1183960 - 26 L_CIR_RX1_LB O
27 LED_GROUND - 28 LED_GROUND -
C.45 CN7000 Volume Board to M/B Connector (8-Pin)
Table C-45 Volume Board to M/B Connector Pin Assignments (8-Pin)
Pin No. Signal Name I/O Pin No. Signal Name I/O
1 +VLED_VL O 2 +VLED_VL O
3 - - 4 - -
5 VL_GROUND - 6 VOL_B_VL O
7 VL_GROUND - 8 VOL_A_VL O
C.46 JACK800 IR Blaster-2 Connector (6-Pin)
Table C-46 IR Blaster-2 Connector Pin Assignments (6-Pin)
Pin No. Signal Name I/O Pin No. Signal Name I/O
1 DGND - 2 N$1163015 -
3 DGND - 4 IRTX2-DET# I
5 DGND - 6 DGND -
C.47 JACK801 IR Blaster-1 Connector (6-Pin)
Table C-47 IR Blaster-1 Connector Pin Assignments (6-Pin)
Pin No. Signal Name I/O Pin No. Signal Name I/O
1 DGND - 2 N$1163007 -
3 DGND - 4 IRTX1-DET# I
5 DGND - 6 DGND -
C.48 JACK802 RJ45 LAN Connector (12-Pin)
Table C-48 RJ45 LAN Connector Pin Assignments (12-Pin)
To Next Page
