Appendices Apx. C Pin Assignments
Qosmio F40/F45 Maintenance Manual C-13
53 DGND - 54 DGND -
55 M_DATA(18) I/O 56 M_DATA(22) I/O
57 M_DATA(19) I/O 58 M_DATA(23) I/O
59 DGND - 60 DGND -
61 M_DATA(24) I/O 62 M_DATA(28) I/O
63 M_DATA(25) I/O 64 M_DATA(29) I/O
65 DGND - 66 DGND -
67 M_DM(3) I/O 68 M_DQS#(3) I/O
69 - - 70 M_DQS(3) I/O
71 DGND - 72 DGND -
73 M_DATA(26) I/O 74 M_DATA(30) I/O
75 M_DATA(27) I/O 76 M_DATA(31) I/O
77 DGND - 78 DGND -
79 M_CKE0 O 80 M_CKE1 O
81 +V1.8 O 82 +V1.8 O
83 - - 84 - -
85 MA_BS2# O 86 M_A(14) I/O
87 +V1.8 O 88 +V1.8 O
89 M_A(12) I/O 90 M_A(11) I/O
91 M_A(9) I/O 92 M_A(7) I/O
93 M_A(8) I/O 94 M_A(6) I/O
95 +V1.8 O 96 +V1.8 O
97 M_A(5) I/O 98 M_A(4) I/O
99 M_A(3) I/O 100 M_A(2) I/O
101 M_A(1) I/O 102 M_A(0) I/O
103 +V1.8 O 104 +V1.8 O
105 M_A(10) I/O 106 MA_BS1# I/O
107 MA_BS0# I/O 108 MA_RAS# I/O
109 M_WE# I/O 110 M_CS0# I/O
111 +V1.8 O 112 +V1.8 O
113 M_CAS# O 114 M_ODT0 O
115 M_CS1# O 116 M_A(13) O
117 +V1.8 O 118 +V1.8 O
119 M_ODT1 O 120 - -
121 DGND - 122 DGND -
123 M_DATA(32) I/O 124 M_DATA(36) I/O
125 M_DATA(33) I/O 126 M_DATA(37) I/O
To Next Page
