4 Replacement Procedures 4.3 ODD Bay Module
ODD bezel
ODD bay module
Latch
Figure 4-11 Removing the Bezel from the ODD drive
Assembling the ODD Drive
Assemble the ODD drive according to the following procedures and Figure 4-10, 4-11.
1. Place the ODD bezel in the correct position and secure the following 4 latches.
2. Seat the bracket and secure it with four M2x3 black flat-head screws.
4-26 Qosmio F40/F45 Maintenance Manual
