Appendices Apx. C Pin Assignments
C-4 Qosmio F40/F45 Maintenance Manual
C.3 CN3 Internal Speaker Connector (4-Pin)
Table C-3 Internal Speaker Connector Pin Assignments (4-Pin)
Pin No. Signal Name I/O Pin No. Signal Name I/O
1 SPK_OUT_L- O 2 SPK_OUT_L+ O
3 SPK_OUT_R- O 4 SPK_OUT_R+ O
C.4 CN4 Hot Key Board Connector (16-Pin)
Table C-4 Hot Key Board Connector Pin Assignments (16-Pin)
Pin No. Signal Name I/O Pin No. Signal Name I/O
1 SCAN_OUT(1) O 2 SCAN_OUT(4) O
3 SCAN_OUT(2) O 4 SCAN_IN(0) I
5 SCAN_IN(7) I 6 SCAN_IN(3) I
7 SCAN_IN(4) I 8 SCAN_IN(5) I
9 SCAN_IN(1) I 10 DOBLY O
11 TV_OUT O 12 N$1111693 -
13 MACHINE_ID0_DB O 14 MACHINE_ID1_DB O
15 DGND - 16 DGND -
C.5 CN5 Camera Module Connector (5-Pin)
Table C-5 Camera Module Connector Pin Assignments (5-Pin)
Pin No. Signal Name I/O Pin No. Signal Name I/O
1 +V5S_CAMERA O 2 USB_P7- I/O
3 USB_P7+ I/O 4 DGND -
5 DGND - - - -
C.6 CN6 Internal Microphone Connector (2-Pin)
Table C-6 Internal Microphone Connector Pin Assignments (2-Pin)
Pin No. Signal Name I/O Pin No. Signal Name I/O
1 ANAGND - 2 MIC_IN I
