Appendices Apx. C Pin Assignments
C-6 Qosmio F40/F45 Maintenance Manual
5 MS_DATA2_SD_DAT2_SM_D2 I/O 6 MS_CDZ I/O
7 MS_DATA3_SD_DAT3_SM_D3 I/O 8 MS_CLK_SD_CLK_SM_ELWPZ I/O
9 VCC_MC O 10 DGND -
11 MS_DATA2_SD_DAT2_SM_D2 I/O 12 MS_DATA3_SD_DAT3_SM_D3 I/O
13 MS_BS_SD_CMD_SM_WEZ I/O 14 DGND -
15 VCC_MC O 16 MS_CLK_SD_CLK_SM_ELWPZ I/O
17 DGND - 18 - -
19 MS_DATA0_SD_DAT0_SM_D0 I/O 20 MS_DATA1_SD_DAT1_SM_D1 I/O
21 SD_CDZ I/O 22 DGND -
23 XD_CDZ I/O 24 DGND -
25 SM_RBZ I/O 26 SM_REZ I/O
27 SD_WP_SM_CEZ I/O 28 SM_CLE I/O
29 SM_ALE I/O 30 MS_BS_SD_CMD_SM_WEZ I/O
31 N$1143854 - 32 DGND -
33 MS_DATA0_SD_DAT0_SM_D0 I/O 34 MS_DATA1_SD_DAT1_SM_D1 I/O
35 MS_DATA2_SD_DAT2_SM_D2 I/O 36 MS_DATA3_SD_DAT3_SM_D3 I/O
37 SM_D4 I/O 38 SM_D5 I/O
39 SM_D6 I/O 40 SM_D7 I/O
41 VCC_MC O 42 - -
43 SD_WP_SM_CEZ I/O 44 DGND -
C.9 CN9 Volume Board Connector (8-Pin)
Table C-9 Volume Board Connector Pin Assignments (8-Pin)
Pin No. Signal Name I/O Pin No. Signal Name I/O
1 VOL_A I 2 DGND -
3 VOL_B I 4 DGND -
5 LED_DIMM#_BUFFER O 6 - -
7 +VLED O 8 +VLED O
C.10 CN11 Felica Card Connector (6-Pin)
Table C-10 Felica Card Connector Pin Assignments (6-Pin)
Pin No. Signal Name I/O Pin No. Signal Name I/O
1 +V5S_FELICA O 2 USB_P9- I/O
3 USB_P9+ I/O 4 DGND -
