E6581528
G-8
7
Parameter setting
Positive
logic
Negative
logic
Function Operation output specifications (in case of positive logic)
 
Specified data output
1
 
Specified data output
2
 
Specified data output
3
 
Specified data output
4
 
Specified data output
5
 
Specified data output
6
 
Specified data output
7
Output of the designated data in 7-bit.
  Light load output ON:Load is equal to ~ set values or less.
  Heavy load output ON:Load is larger than ~ set value.
  Positive torque limit ON:Positive torque is over the positive torque limit level.
  Negative torque limit ON:Negative torque is over the positive torque limit level.
 
Output for external rush
suppression relay
ON:External rush suppression relay is actuated.
 
Completion of stop
positioning
ON:Stop positioning has been completed.
  L-STOP
ON:Operation at the lower limit frequency is performed
continuously.
 
Power failure
synchronized operation
ON:Power failure synchronized operation is performed.
  Traverse in progress ON:Traverse operation is performed.
 
Traverse deceleration in
progress
ON:Traverse deceleration operation is performed.
  Part replacement alarm Alarm:The time of replacement of parts is approaching.
  Over-torque pre-alarm ON:Over-torque is detected.
 
Frequency command 1/
2 selection
ON:Frequency command selection 2 is selected.
 
Failure FL (Except
emergency stop)
ON:A trip other than emergency stop has occurred.
  My function output 1 ON:My function output 1 is ON.
  My function output 2 ON:My function output 2 is ON.
  My function output 3 ON:My function output 3 is ON.
  My function output 4 ON:My function output 4 is ON.
  My function output 5 ON:My function output 5 is ON.
  My function output 6 ON:My function output 6 is ON.
  My function output 7 ON:My function output 7 is ON.
  My function output 8 ON:My function output 8 is ON.
  My function output 9 ON:My function output 9 is ON.
  My function output 10 ON:My function output 10 is ON.
  My function output 11 ON:My function output 11 is ON.
  My function output 12 ON:My function output 12 is ON.
  My function output 13 ON:My function output 13 is ON.
  My function output 14 ON:My function output 14 is ON.
  My function output 15 ON:My function output 15 is ON.
  My function output 16 ON:My function output 16 is ON.
 
A
lways OFF (for terminal
signal tests)
Output signal always OFF
Note 1: “ON” in positive logic : Open collector output transistor or relay is turned on.
“OFF” in positive logic : Open collector output transistor or relay is turned off.
“ON” in negative logic : Open collector output transistor or relay is turned off.
“OFF” in negative logic : Open collector output transistor or relay is turned on.
Note 2: Alarm output check conditions are as follows.
(1) Undervoltage detected :To be checked during operation.
(2) Low current detected : To be checked during operation command.
(3) Overtorque detected : To be checked always.
 Sink logic/source logic
Sink logic and source logic (logic of input/output terminal) can be switched to each other.
⇒ For details, refer to Section 2.3.2.
