Toshiba TOSVERT VF-AS1 - Page 246

E6581528
J-3
10
Power supply voltage 500V
No-fuse breaker (MCCB) Magnetic contactor (MC)
Input current[A]
Without
Reactor
With
Reactor
Without
Reactor
With
Reactor
Inverter model
Applicable
motor
(kW)
Without
Reactor
With
Reactor
Rated current
[A]
Rated current
[A]
Operationl
current [A]
AC-1
Operationl
current [A]
AC-1
VFAS1-5015PM 1.5 5.6 2.7 7.5 5 7.5 5
VFAS1-5022PM 2.2 7.6 3.9 10 7.5 10 5
VFAS1-5030PM 3 9.9 5.2 15 7.5 15 7.5
VFAS1-5040PM 4 12.5 6.9 17.5 10 15 10
VFAS1-5055PM 5.5 16.4 9.4 25 15 20 15
VFAS1-5075PM 7.5 21.4 12.6 30 17.5 25 15
VFAS1-6150PL 11 - 2 0 . 2 - 3 0 - 25
VFAS1-6185PL 15 - 24 - 35 - 30
VFAS1-6220PL 18.5 - 27 - 40 - 30
VFAS1-6300PL 22 - 34 - 50 - 40
VFAS1-6370PL 30 - 47 - 65 - 60
VFAS1-6450PL 37 - 55 -
80
- 60
VFAS1-6550PL 45 - 63 -
100
- 80
VFAS1-6750PL 55 - 88 - 125 - 100
VFAS1-6900PL 75 - 101 - 150 - 125
VFAS1-6110KPC 90 - 117 - 175 - 150
VFAS1-6132KPC 110 - 137 - 200 - 175
VFAS1-6160KPC 132 - 163 - 250 - 200
VFAS1-6200KPC 160 - 212 - 300 - 250
VFAS1-6250KPC 185 - 256 - 350 - 300
VFAS1-6315KPC 250 - 317 - 450 - 350
VFAS1-6400KPC 315 - 409 - 600 - 450
VFAS1-6500KPC 400 - 498 - 700 - 550
VFAS1-6630KPC 500 - 616 - 900 - 700
Power supply voltage 600V
No-fuse breaker (MCCB) Magnetic contactor (MC)
Input current[A]
Without
Reactor
With
Reactor
Without
Reactor
With
Reactor
Inverter model
Applicable
motor
(HP)
Without
Reactor
With
Reactor
Rated current
[A]
Rated current
[A]
Operationl
current [A]
AC-1
Operationl
current [A]
AC-1
VFAS1-5015PM 2HP
4.9 2.3 7.5 5 7.5 5
VFAS1-5022PM 3HP
6.7 3.3 10 5 7.5 5
VFAS1-5040PM 5HP
10.9 4.4 15 7.5 15 5
VFAS1-5055PM 7.5HP
14.2 5.8 20 10 20 7.5
VFAS1-5075PM 10HP
18.4 10.6 25 15 20 15
VFAS1-6150PL
15HP
- 18 - 25 - 20
VFAS1-6185PL 20HP
- 23 - 35 - 25
VFAS1-6220PL 25HP
- 26 - 40 - 30
VFAS1-6300PL 30HP
- 30 - 50 - 40
VFAS1-6370PL 40HP
- 45 - 65 - 50
VFAS1-6450PL 50HP
- 56 - 80 - 80
VFAS1-6550PL 60HP
- 61 - 100 - 80
VFAS1-6750PL 75HP
- 77 - 125 - 100
VFAS1-6900PL 100HP
- 98 - 150 - 125
VFAS1-6110KPC 125HP
- 113 - 175 - 125
VFAS1-6160KPC 150HP
- 159 - 225 - 175
VFAS1-6200KPC 200HP
- 204 - 300 - 225
VFAS1-6250KPC 250HP
- 249 - 350 - 300
VFAS1-6315KPC 350HP
- 311 - 450 - 350
VFAS1-6400KPC 450HP
- 401 - 600 - 450
VFAS1-6500KPC 550HP
- 491 - 700 - 550
VFAS1-6630KPC 700HP
- 613 - 900 - 700
