E6581528
J-4
10
Power supply voltage 690V
No-fuse breaker (MCCB) Magnetic contactor (MC)
Input current[A]
Without
Reactor
With
Reactor
Without
Reactor
With
Reactor
Inverter model
Applicable
motor
(kW)
Without
Reactor
With
Reactor
Rated current
[A]
Rated current
[A]
Operationl
current [A]
AC-1
Operationl
current [A]
AC-1
VFAS1-6022PL 2.2
-
4.0
-
7.5
-
5
VFAS1-6030PL 3
- 5.2 - 7.5 - 7.5
VFAS1-6055PL 5.5
- 8.6 - 12.5 - 10
VFAS1-6075PL 7.5
- 11.2 - 15 - 15
VFAS1-6110PL 11
- 15.5 - 25 - 20
VFAS1-6150PL 15
- 20.2 - 30 - 25
VFAS1-6185PL 18.5
- 24 - 35 - 30
VFAS1-6220PL 22
- 27 - 40 - 30
VFAS1-6300PL 30
- 34 - 50 - 40
VFAS1-6370PL 37
- 47 - 65 - 60
VFAS1-6450PL 45
- 55 - 80 - 60
VFAS1-6550PL 55
- 63 - 100 - 80
VFAS1-6750PL 75
- 88 - 125 - 100
VFAS1-6900PL 90
- 101 - 150 - 125
VFAS1-6110KPC 110
- 117 - 175 - 150
VFAS1-6132KPC 132
- 137 - 200 - 150
VFAS1-6160KPC 160
- 163 - 225 - 200
VFAS1-6200KPC 185
- 212 - 300 - 250
VFAS1-6250KPC 250
- 256 - 350 - 300
VFAS1-6315KPC 315
- 317 - 450 - 350
VFAS1-6400KPC 400
- 409 - 600 - 450
VFAS1-6500KPC 500
- 498 - 700 - 550
VFAS1-6630KPC 630
- 616 - 900 - 700
(*1): Choose the MCCB according to the power supply capacity.
For comply with UL and CSA standard, use the fuse certified by UL and CSA.
(*2): When using on the motor side during commercial-power supply operation, choose the MC with class AC-3 rated current
for the motor rated current.
(*3): Attach surge killers to the magnetic contactor and exciting coil of the relay.
(*4): In the case the magnetic contactor (MC) with 2a-type auxiliary contacts is used for the control circuit, raise the reliability
of the contact by using 2a-type contacts in parallel connection.
(*5): For 200V/55kW model and larger and 400V/90kW model and larger, be sure to install a DC reactor.
