E6581528
A-18
1
VFAS1-6200KPC, 6250KPC, 6315KPC
VFAS1-6400KPC, 6500KPC, 6630KPC
Terminals
R0, S0, T0
Terminals
R0, S0, T0
Modification for fans
powered externally by R0, S0, T0
Factory wiring:
Fans powered internally by
R/L1, S/L2, T/L3
Modification for fans powered externally by R0, S0, T0
Factory wiring: Fans powered internally by R/L1, S/L2, T/L3
Terminals
R0, S0, T0
Terminals
R0, S0, T0
