Toshiba TOSVERT VF-PS1 User Manual

E6581386
G-7
7
Parameter setting
Positive
logic
Negative
logic
Function Operation output specifications (in case of positive logic)
  Low current detection
ON: The state that inverter output current is
 set value
or larger continued more than
 set value.
  Over-torque detection
ON:The state that torque component is
,  set
value or larger continued more than
 set value.
 
Braking resistor
overload pre-alarm
ON:A certain rate of braking resister overload trip (
)
detection time is over.
OFF:The detection time is within a certain limit.
  In emergency stop
ON:In emergency stop operation (
 is indicated).
OFF:The detection time is within a certain limit.
  In retry
ON:In retry operation (
 is indicated).
OFF:No retry operation is performed.
  PID deviation limit ON:PID deviation is in  or  set value.
  Run/Stop
ON:Running frequency is output or DC injection breaking
(
) is performed.
 
Serious failure (OCA,
OCL, EF, phase failure,
etc.)
ON:Serious failure (, , , phase failure,
abnormal output, short-circuit) is detected.
OFF:Inverter has recovered from serious failure. (Serious
failure has been reset)
 
Light failure (OL, OC1, 2,
3, OP)
ON:Light failure (
, , , , ) is detected.
OFF:Inverter has recovered from light failure. (Light failure has
been reset)
 
Commercial
power/inverter switching
output 1
Refer to Section 6.17.
 
Commercial
power/inverter switching
output 2
Refer to Section 6.17.
  Cooling fan ON / OFF
ON:Cooling fan is in operation.
OFF:Cooling fan is off operation.
 
In jogging operation (In
jog run)
ON:In jog run
OFF:In normal operation
 
Operation
panel/terminal board
operation switching
ON:In operation by terminal board.
OFF:In operation by operation panel.
 
Cumulative operation
time alarm
ON:Cumulative operation time is beyond the
 set
value.
OFF:Cumulative operation time is less than the
 set
value.
 
PROFIBUS/DeviceNet/CC-Li
nk communication error
ON:Communication error occurred.
OFF:Communication error is canceled (reset).
 
Forward/reverse
switching
OFF:In forward operation.
ON:In reverse operation.
It output command status while operation is stopped.
(When command status is not active, It will be "OFF")
  Ready for operation 1
ON:In operable status (exclude during deceleration stop) or
operation can be started with frequency command input as an
operation switching answer-back.
OFF:In inoperable status.
  Ready for operation 2
ON:In operable status or operation can be started with RUN
signal and frequency command input.
OFF:In inoperable status.
  In (pre-)alarm status
ON:More than one of alarm, pre-alarm, undervoltage, low
current over-torque, poor control power supply, PID deviation
limit, abnormal frequency setting or torque limit have occurred
or detected.
OFF:All the alarms above are canceled.
  Inverter healthy output ON and OFF are alternately output at intervals of 1 second.
 
RS485 communication
error
ON:Communication error occurred.
OFF:Communication error is canceled (reset).
  Error code output 1
  Error code output 2
  Error code output 3
  Error code output 4
  Error code output 5
  Error code output 6
Output the error code in 6-bit.
  Specified data output 1
  Specified data output 2
Output of the designated data in 7-bit.
