Toshiba TOSVERT VF-PS1 User Manual

K-14
E6581386
11
[16] PID control [2/2] Sensorless vector/PG feedback control (●:Effective, -:Ineffective)
Title
Communi
cation
No.
Function Adjustment range
Minimum
setting unit
(Panel/Communi
cation)
Default
setting
Write during
running
Vector
control
PM
control
V/f Reference
 0365 PID deviation lower limit ~ Hz 0.1/0.01 *2 Enabled ●/● ● ● 6. 18 *1
 0366 Differential (D) gain 0.00~2.55 0.01/0.01 0.00 Enabled ●/● ● ● 6. 18 *1
 0367 Process upper limit ~ Hz 0.1/0.01 *2 Enabled ●/● ● ● 6. 18 *1
 0368 Process lower limit ~ Hz 0.1/0.01 0.0 Enabled ●/● ● ● 6. 18 *1
 0369 PID control waiting time 0~2400 sec. 1/1 0 Enabled ●/● ● ● 6. 18 *1
 0370 PID output upper limit ~ Hz 0.1/0.01 *2 Enabled ●/● ● ● 6. 18 *1
 0371 PID output lower limit ~ Hz 0.1/0.01 0.0 Enabled ●/● ● ● 6. 18 *1
 0372
Process increasing rate (speed type PID
control)
0.1~600.0 0.1/0.1 10.0 Enabled ●/● ● ● 6. 18 *1
 0373
Process decreasing rate (speed type PID
control)
0.1~600.0 0.1/0.1 10.0 Enabled ●/● ● ● 6. 18 *1
 0374
Frequency command agreement detection
range
0.0~ Hz 0.1/0.01 2.5 Enabled ●/● ● ● 6. 18 *1
*1:  For details, refer to Instruction Manual (E6581329) specified in Section 6.36.
*2: Inverter with a model number ending with -WN: 60.0 -WP: 50.0
[17] Speed feedback/positioning control Sensorless vector/PG feedback control (●:Effective, -:Ineffective)
Title
Communi
cation
No.
Function Adjustment range
Minimum
setting unit
(Panel/Communi
cation)
Default
setting
Write during
running
Vector
control
PM
control
V/f Reference
 0375 Number of PG input pulses 12~9999 1/1 500 Disabled -/● - - *1
 0376 Selection of number of PG input phases
1:Single-phase input
2:Two-phase input
3:Two-phase input (Inversion of polarity)
1/1 2 Disabled -/● - - *1
 0377 PG disconnection detection
0:Disabled
1:Enabled (with filter)
2:Enabled (Detection of momentary power failure)
1/1 0 Disabled -/● - - *1
 0378 Number of RP terminal input pulses 12~9999 1/1 500 Disabled ●/● ● ● *2
 0379 PID output dead band 0~100% 1/1 0 Enabled ●/● ● ● *3
*1:  For details, refer to Instruction Manual (E6581319) specified in Section 6.36.
*2:  For details, refer to Instruction Manual (E6581341) specified in Section 6.36.
*3:  For details, refer to Instruction Manual (E6581329) specified in Section 6.36.
