TD-8811 ADSL2+ Modem Router User Guide
56
Figure 4-33
To add a new entry, follow the steps below.
1. Click the Add button in Figure 4-33 to go to the S
tatic Route Add page as shown in Figure
4-34.
2. Enter the IP address of the destination network. This parameter specifies the IP network
address of the final destination.
3. Enter the Subnet Mask for the destination.
4. Select the Use Gateway IP Address checkbox and enter the IP address of the gateway.
The gateway is an immediate neighbor of your ADSL Router that will forward the packet to
the destination. On the LAN, the gateway must be a router on the same segment as your
Router; over Internet (WAN), the gateway must be the IP address of one of the remote
nodes.
5. Click Save/Apply to save your configurations. Then you will go back to Figure 4-33 and
see your ne
w entry.
Figure 4-34
4.3.6 DSL
Choose “Advanced Setup→DSL” menu, you can view and configure the parameters in the
screen as shown in Figure 4-35.

TP-Link TD-8811 Specifications

General

Connectivity LEDs	Yes
Dimensions (WxDxH)	165 x 108 x 28 mm
Connectivity technology	Wired
Maximum data transfer rate	0.1 Gbit/s
Supported data transfer rates	10/100 Mbps
Networking standards	IEEE 802.1d
Ethernet LAN data rates	10, 100 Mbit/s
Routing protocols	IP
Supported network protocols	PPPoE, RFC 2364
DSL specification	ANSI T1.413 Issue 2, ITU-T G.992.1, ITU-T G.992.2, ITU-T G.994.1, ITU-T G.992.3, ITU-T G.992.5
Ethernet LAN (RJ-45) ports	1
Firewall security	Network address translation (NAT) firewall, Stateful packet inspection (SPI) firewall
Security algorithms	802.1x RADIUS
Filtering description	Domain
Product color	Black, White
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Power consumption (typical)	4.1 W

Weight and Dimensions

Weight	300 g
