Bit coded operating parameters
Byte
X+0
Bit
7 – 0
Data
2
7
– 2
0
x = default setting
Bit
Definition
= 0
= 1
Page
0
Interpolation
off
X
on
80
1
Counting direction
increasing position values
to the rod end
X
decreasing position
values to the rod end
81
Operating parameter Resolution
Description see page 82
unsigned16
Byte
X+1
X+2
Bit
15 – 8
7 – 0
Data
2
15
– 2
8
2
7
– 2
0
Default (dec.)
5 µm (1…1000)
Resolution
Operating parameter Number of magnets
Description see page 82
bitarea
Byte
X+3
Bit
7
6
5
4
3
2
1
0
Data
2
7
2
6
2
5
2
4
2
3
2
2
2
1
2
0
1 magnet (default)
0
0
0
0
0
0
0
1
2 magnets
0
0
0
0
0
0
1
0
3 magnets
0
0
0
0
0
0
1
1
