Parameterization and configuration
 TR-Electronic GmbH 2009, All Rights Reserved Printed in the Federal Republic of Germany
Page 78 of 92 TR - ELA - BA - DGB - 0015 - 13 04/23/2020
Overview of operating parameters
see note on page 72
Parameter
Data type
Byte
Format
Description
Interpolation
bit
x+0
page 78
page 80
Counting direction
bit
x+0
page 78
page 81
Resolution
unsigned16
x+1 – x+2
page 78
page 82
Number of magnets
bitarea
x+3
page 79
page 82
Observer
unsigned8
x+4
page 79
page 82
Averaging
unsigned8
x+5
page 79
page 83
Unit v
unsigned32
x+6 – x+9
page 79
page 83
Option 1
unsigned16
x+10 – x+11
page 80
page 83
Option 2
unsigned32
x+12 – x+15
in preparation
Bit coded operating parameters
Byte
X+0
Bit
7 – 0
Data
2
7
– 2
0
x = default setting
Bit
Definition
= 0
= 1
Page
0
Interpolation
off
X
on
80
1
Counting direction
increasing position values
to the rod end
X
decreasing position
values to the rod end
81
Operating parameter Resolution
Description see page 82
unsigned16
Byte
X+1
X+2
Bit
15 – 8
7 – 0
Data
2
15
– 2
8
2
7
– 2
0
Default (dec.)
5 µm (1…1000)
Resolution
