Trail Tech Vector - Installation: Part 1; Mounting the Computer Unit; Temperature Sensor Installation

11
Installation
Place bolts as
shown in picture.
Remember to
use provided
nuts when
placing bolts.
Bar Mounting:
Please see model-specific
instructions for mounting procedure.
Temperature
Sensors:
Temperature Sensor
in-line in radiator hose for
water-cooled machines
RADIATOR
HOSE
TEMP.
SENSOR
Cylinder Head Temperature
Sensor for air-cooled machines
SPARK
PLUG
