Trail Tech Vector - Backlight; Using External 12 V Power; Using Internal Battery Only

Parts & Features
9
TO ACTIVATE BACKLIGHT MANUALLY, PRESS
Backlight:
Vector is equipped with a backlight for easy viewing during night-time
operation.
Using External 12V Power:
•
•
•
Using Internal Battery Only:
•
•
•
•
Vector will light up with all five LED’s.
Vector will remain lit as long as it senses wheel movement. After
20 minutes of inactivity Vector shuts off the backlight. Press any
button, roll the wheels, or start the motor power and Vector will light
up again.
Shift and temperature LED’s will be enabled.
Vector will only stay lit for 3 seconds.
Vector’s backlight will light up with 10% power to conserve the
internal battery’s power.
If the LO symbol is present, the backlight will not turn on. The LO
symbol appears when battery voltage drops below 2.45V.
If ambient temperature is cold (below -5°C) the backlight will not
turn on.
