Trane CGAM - Page 177

CG-SVX17D-EN 177
Diagnostics
Comm Loss: External Ice
Building Control Input
Comm Loss: Ext Ice Building
Ctrl Input
Comm: Ext Ice Building Ctrl
Chiller Warning Latch All
Continual loss of communication
between the MP and the Functional ID
has occurred for a 35-40 second period.
Chiller shall revert to normal (non-ice
building) mode regardless of last state.
Remote
Comm Loss: Outdoor Air
Temperature
Comm Loss: Outdoor Air
Temperature
Comm: Outdoor Air Temp
Chiller Normal Latch All
Continual loss of communication
between the MP and the Functional ID
has occurred for a 35-40 second period.
Remote
Comm Loss: Evap Leaving
Water Temp
Comm Loss: Evap Leaving
Water Temp
Comm: Evap Leav Water
Temp
Chiller Normal Latch All
Continual loss of communication
between the MP and the Functional ID
has occurred for a 35-40 second period.
Remote
Comm Loss: Evap Entering
Water Temp
Comm Loss: Evap Entering
Water Temp
Comm: Evap Ent Water
Temp
Chiller Normal Latch All
Continual loss of communication
between the MP and the Functional ID
has occurred for a 35-40 second period.
Remote
Comm Loss: Discharge Pressure
Transducer
Comm Loss: Discharge Pressure
Transducer
Comm: Discharge Press Xdcr
Circuit Immediate Latch All
Continual loss of communication
between the MP and the Functional ID
has occurred for a 35-40 second period.
Remote
Comm Loss: Suction Pressure
Transducer
Comm Loss: Suction Pressure
Transducer
Comm: Suction Pressure
Xdcr
Circuit Immediate Latch All
Continual loss of communication
between the MP and the Functional ID
has occurred for a 35-40 second period.
Remote
Comm Loss: Ext Chilled/Hot Wtr
Setpoint
Comm Loss: Ext Chilled/Hot Wtr
Setpoint
Comm: Ext Chil/Hot Wtr
Setpt
Chiller
Warning and
Special
Action
Latch All
Continual loss of communication
between the MP and the Functional ID
has occurred for a 35-40 second period.
Chiller shall discontinue use of the
External Chilled/Hot Water Setpoint
source and revert to the next higher
priority for setpoint arbitration
Remote
Comm Loss: Ext Demand Limit
Setpoint
Comm Loss: Ext Demand Limit
Setpoint
Comm: Ext Demand Limit
Setpt
Chiller
Warning and
Special
Action
Latch All
Continual loss of communication
between the MP and the Functional ID
has occurred for a 35-40 second period.
Chiller shall discontinue use of the
External Demand Limit Setpoint source
and revert to the next higher priority for
setpoint arbitration
Remote
Comm Loss: Auxiliary Setpoint
Command
Comm Loss: Auxiliary Setpoint
Command
Comm: Auxiliary Setpt Cmd
Chiller
Warning and
Special
Action
Latch All
Continual loss of communication
between the MP and the Functional ID
has occurred for a 35-40 second period.
Chiller shall discontinue use of the
Auxiliary Setpoint and revert to the
Chilled Water Setpoint based on
setpoint arbitration
Remote
Comm Loss: High Pressure
Cutout Switch
Comm Loss: High Pressure
Cutout Switch
Comm: High Press Cutout
Sw
Circuit Immediate Latch All
Continual loss of communication
between the MP and the Functional ID
has occurred for a 35-40 second period.
Remote
