Trane CGAM - Page 178

178 CG-SVX17D-EN
Diagnostics
Comm Loss: Evaporator Water
Flow Switch
Comm Loss: Evaporator Water
Flow Switch
Comm: Evap Water Flow Sw
Chiller Immediate Latch All
Continual loss of communication
between the MP and the Functional ID
has occurred for a 35-40 second period.
Remote
Comm Loss: Local BAS Interface
Comm Loss: Local BAS Interface
Comm: Local BAS Interface
Chiller
Warning and
Special
Action
NonLatch All
Continual loss of communication
between the MP and the Functional ID
has occurred for a 35-40 second period.
Use the last values sent from BAS.
Remote
Comm Loss: Compressor Fault
Input
Comm Loss: Compressor Fault
Input
Comm: Compressor Fault
Input
Cprsr Immediate Latch All
Continual loss of communication
between the MP and the Functional ID
has occurred for a 35-40 second period.
Remote
Comm Loss: Compressor Run
Command
Comm Loss: Compressor Run
Command
Comm: Cprsr Run Command
Cprsr Immediate Latch All
Continual loss of communication
between the MP and the Functional ID
has occurred for a 35-40 second period.
Remote
Comm Loss: Fan Control Relays
Comm Loss: Fan Control Relays
Comm: Fan Control Relays
Circuit Immediate Latch All
Continual loss of communication
between the MP and the Functional ID
has occurred for a 35-40 second period.
Remote
Comm Loss: Fan Fault
Comm Loss: Fan Fault
Comm: Fan Fault
Circuit Warning Latch All
Continual loss of communication
between the MP and the Functional ID
has occurred for a 35-40 second period.
Remote
Comm Loss: Fan Inverter Speed
Command
Comm Loss: Fan Inverter Speed
Command
Comm: Fan Inverter Speed
Cmd
Circuit
Warning and
Special
Action
NonLatch All
Continual loss of communication
between the MP and the Functional ID
has occurred for a 35-40 second period.
Revert to fixed-speed fan algorithm
using remaining fans.
Remote
Comm Loss: Fan Inverter Fault
Comm Loss: Fan Inverter Fault
Comm: Fan Inverter Fault
Circuit
Warning and
Special
Action
Latch All
Continual loss of communication
between the MP and the Functional ID
has occurred for a 35-40 second period.
Revert to fixed-speed fan algorithm
using remaining fans.
Remote
Comm Loss: Op Status
Programmable Relays
Comm Loss: Op Status
Programmable Relays
Comm: Op Status Relays
Chiller Warning Latch All
Continual loss of communication
between the MP and the Functional ID
has occurred for a 35-40 second period.
Remote
Comm Loss: Anti-Freeze Heater
Relay
Comm Loss: Anti-Freeze Heater
Relay
Comm: Anti-Freeze Heater
Rly
Chiller
Warning and
Special
Action
Latch All
Continual loss of communication
between the MP and the Functional ID
has occurred for a 35-40 second period.
Remote
Comm Loss: Evaporator Water
Pump 1 Relay
Comm Loss: Evaporator Water
Pump 1 Relay
Comm: Evap Water Pump
Relay
Chiller Normal Latch All
Continual loss of communication
between the MP and the Functional ID
has occurred for a 35-40 second period.
Remote
