Trane CGAM - Page 180

180 CG-SVX17D-EN
Diagnostics
Comm Loss: External Night
Noise Setback Input
Comm Loss: Ext Night Noise
Setback Input
Comm: Ext Night Noise Inp
Chiller
Warning and
Special
Action
Latch All
Continual loss of communication
between the MP and the Functional ID
has occurred for a 35-40 second period.
External input is excluded from
arbitration logic per standard
arbitration rules.
Remote
Comm Loss: Night Noise
Setback Relay
Comm Loss: Night Noise
Setback Relay
Comm: Night Noise Setbk
Rly
Chiller Normal Latch All
Continual loss of communication
between the MP and the Functional ID
has occurred for a 35-40 second period.
Remote
Comm Loss: Phase Protection
Fault Input
Comm Loss: Phase Protection
Fault Input
Comm: Phase Protect Flt
Inp
Chiller Normal Latch All
Continual loss of communication
between the MP and the Functional ID
has occurred for a 35-40 second period.
Remote
Comm Loss: Discharge
Temperature Sensor
Comm Loss: Discharge
Temperature Sensor
Comm: Discharge Temp
Sensor
Circuit Immediate Latch All
Continual loss of communication
between the MP and the Functional ID
has occurred for a 35-40 second period.
Remote
Comm Loss: Subcooler Shutoff
Valve Relay
Comm Loss: Subcooler Shutoff
Valve Relay
Comm: Subcooler Shut Vlv
Rly
Circuit Normal Latch All
Continual loss of communication
between the MP and the Functional ID
has occurred for a 35-40 second period.
Remote
Comm Loss: Reversing Valve
Comm Loss: Reversing Valve
Comm: Reversing Valve
Circuit Normal Latch All
Continual loss of communication
between the MP and the Functional ID
has occurred for a 35-40 second period.
Remote
Comm Loss: Percent Capacity
Output
Comm Loss: Percent Capacity
Output
Comm: Percent Capacity
Out
Chiller Warning Latch All
Continual loss of communication
between the MP and the Functional ID
has occurred for a 35-40 second period.
Remote
Comm Loss: Receiver Fill Valve
Relay
Comm Loss: Receiver Fill Valve
Relay
Comm: Receiver Fill Vlv Rly
Circuit Normal Latch All
Continual loss of communication
between the MP and the Functional ID
has occurred for a 35-40 second period.
Remote
Comm Loss: Power Factor
Correction Fault
Comm Loss: Power Factor
Correction Fault
Comm: Pwr Fac Correction
Flt
Chiller Warning Latch All
Continual loss of communication
between the MP and the Functional ID
has occurred for a 35-40 second period.
Remote
Comm Loss: Supplemental
Heat Relay 1
Comm Loss: Supplemental
Heat Relay 1
Comm: Supplemental Heat
Relay 1
Chiller Warning Latch All
Continual loss of communication
between the MP and the Functional ID
has occurred for a 35-40 second period.
Remote
