Trane CGAM - Page 45

CG-SVX17D-EN 45
Installation - Mechanical
Table 11. CGAM Center of Gravity (in) - 60 Hz
Unit
Base Unit Unit with Pump Package
Unit with Pump Package
and Buffer Tank
XYZ X Y Z X Y Z
Units without partial heat recovery
20 ton492437602332692333
26 ton492437602332692333
30 ton592237742132842233
35 ton592237742132842233
40 ton474533534229594230
52 ton484632534329594330
60 ton604536694335754333
70 ton604636694334754333
80 ton594436684534684533
90 ton594536684534674533
100 ton 72 47 38 81 47 36 80 46 34
110 ton 72 47 38 81 47 36 80 47 34
120 ton 72 47 38 84 47 35 83 46 34
130 ton 86 47 39 100 47 36 101 46 35
Units with partial heat recovery
20 ton492537602332692433
26 ton502436602331692332
30 ton592336742232842233
35 ton592336742232842232
40 ton494533554230604231
52 ton494632554329604330
60 ton614537704335764334
70 ton624636704335764334
80 ton584437674435664533
90 ton584536664534664533
100 ton 71 47 38 80 47 36 79 46 35
110 ton 71 47 38 80 47 36 79 46 35
120 ton 70 47 38 82 47 35 81 46 34
130 ton 85 47 39 99 47 36 99 46 35
