46 CG-SVX17D-EN
Installation - Mechanical
Table 12. CGAM Center of Gravity (in) - 50 Hz
Unit
Base Unit Unit with Pump Package
Unit with Pump Package and
Buffer Tank
XYZ X Y Z X Y Z
Units without partial heat recovery
20 ton492539 58 24 34 68 24 35
26 ton492438 58 24 34 68 24 35
30 ton602338 72 22 33 83 22 34
35 ton602337 73 22 33 84 22 34
40 ton484533 53 43 30 60 43 31
52 ton494633 53 43 30 60 43 31
60 ton614537 70 43 35 76 43 34
70 ton624637 70 43 35 77 43 34
80 ton604437 69 45 35 68 45 34
90 ton604536 68 45 35 68 45 33
100 ton 73 47 39 82 47 37 81 47 35
110 ton 73 47 38 82 47 36 81 47 35
120 ton 73 47 38 83 47 36 82 47 34
Units with partial heat recovery
20 ton502537 58 24 33 68 24 34
26 ton502537 58 24 33 68 24 34
30 ton602337 72 22 33 83 22 34
35 ton602337 73 22 33 84 22 33
40 ton504534 55 43 31 61 43 32
52 ton504633 55 43 30 61 43 31
60 ton634537 71 43 36 77 43 34
70 ton644637 72 43 35 78 43 34
80 ton614438 69 45 35 69 45 34
90 ton614537 69 45 35 68 45 33
100 ton 72 47 39 81 47 37 80 46 35
110 ton 72 47 39 81 47 37 80 47 35
120 ton 74 47 38 84 47 36 83 47 35
