74 CG-SVX17D-EN
Installation - Electrical
80
208/60/3 2 4 6 1 6.2 74-74/74-74 485-485/485-485 358 400 388 450
230/60/3 2 4 6 1 6.7 67-67/67-67 485-485/485-485 331 350 362 400
380/60/3 2 4 6 1 3.7 40-40/40-40 260-260/260-260 194 225 n/a
460/60/3 2 4 6 1 3.2 33-33/33-33 215-215/215-215 162 175 186 200
575/60/3 2 4 6 1 2.6 26-26/26-26 175-175/175-175 131 150 150 175
90
208/60/3 2 4 6 1 6.2 74-91/91-74 485-560/560-485 397 450 428 500
230/60/3 2 4 6 1 6.7 67-85/67-85 485-560/560-485 370 450 401 450
380/60/3 2 4 6 1 3.7 40-55/40-55 260-310/310-260 227 275 n/a
460/60/3 2 4 6 1 3.2 33-42/33-42 215-260/260-215 182 200 206 225
575/60/3 2 4 6 1 2.6 26-34/26-34 175-210/210-175 149 175 168 200
100
208/60/3 2 4 8 1 6.2 91-91/91-91 560-560/560-560 444 500 475 500
230/60/3 2 4 8 1 6.7 85-85/85-85 560-560/560-560 418 500 449 500
380/60/3 2 4 8 1 3.7 55-55/55-55 310-310/310-310 263 300 n/a
460/60/3 2 4 8 1 3.2 42-42/42-42 260-260/260-260 206 225 230 250
575/60/3 2 4 8 1 2.6 34-34/34-34 210-210/210-210 169 200 188 200
110
208/60/3 2 4 8 1 6.2 91-110/110-91 560-680/680-560 485 500 516 600
230/60/3 2 4 8 1 6.7 85-109/109-85 560-680/680-560 473 500 504 600
380/60/3 2 4 8 1 3.7 55-60/60-55 310-360/360-310 275 300 n/a
460/60/3 2 4 8 1 3.2 42-51/51-42 260-320/320-260 226 250 250 250
575/60/3 2 4 8 1 2.6 34-39/39-34 210-235/235-210 179 200 198 225
120
208/60/3 2 4 8 1 6.2 110-110/110-110 680-680/680-680 521 600 n/a
230/60/3 2 4 8 1 6.7 109-109/109-109 680-680/680-680 522 600 568 600
380/60/3 2 4 8 1 3.7 60-60/60-60 360-360/360-360 285 300 n/a
460/60/3 2 4 8 1 3.2 51-51/51-51 320-320/320-320 244 250 268 300
575/60/3 2 4 8 1 2.6 39-39/39-39 235-235/235-235 188 225 207 225
130
208/60/3 2 6 10 1 6.2 74-74-91/91-74-74
485-485-560/
560-485-485
569 600 n/a
230/60/3 2 6 10 1 6.7 67-67-85/85-67-67
485-485-560/
560-485-485
531 600 578 600
380/60/3 2 6 10 1 3.7 40-40-55/55-40-40
260-260-310/
310-260-260
321 350 n/a
460/60/3 2 6 10 1 3.2 33-33-42/42-33-33
215-215-260/
260-215-215
261 300 285 300
575/60/3 2 6 10 1 2.6 26-26-34/34-26-26
175-175-210/
210-175-175
212 225 231 250
1. RLA - Rated Load Amps - Rated in accordance with UL Standard 1995.
2. LRA - Locked Rotor Amps - Based on full winding starts.
3. MCA - Minimum Circuit Ampacity - 125 percent of largest compressor RLA plus 100 percent of all other loads.
4. MOPD or Max fuse size - 225 percent of the largest compressor RLA plus all other loads.
5. Local codes may take precedence.
6. Voltage Utilization Range: +/- 10% of rated voltage
Rated voltage (use range): 208/60/3 (187.2-228.8), 230/60/3(208-254), 380/60/3 (342-418), 460/60/3 (414-506), 575/60/3 (516-633)
7. One separate 120/60/1, 15 amp customer provided power connection is required to power the heaters.
8. n/a - not available
Table 30. Electrical Data - 60 Hz
Unit
Size Rated
Power
Number
Circuits
Qty
Comp
Qty
Fans
Fan
Motor
Power
(kw)
Cond
Fan
FLA
Compressor
RLA¹
Compressor
LRA²
No pump Pump
MCA MOPD MCA MOP
