Trane CGAM - Page 75

CG-SVX17D-EN 75
Installation - Electrical
Table 31. Lug Range Size - 60 Hz
No Pump Pump
Unit Size Rated Power
Terminal
Blocks
Std Fault
Ckt Breaker¹
High Fault
Ckt Breaker¹
Terminal
Blocks
Std Fault
Ckt Breaker¹
High Fault
Ckt Breaker¹
20
208/60/3 #6 - 350 MCM #14 - 1/0 #14 - 1/0 #6 - 350 MCM #6 - 350 MCM #6 - 350 MCM
230/60/3 #6 - 350 MCM #14 - 1/0 #14 - 1/0 #6 - 350 MCM #6 - 350 MCM #6 - 350 MCM
380/60/3 #6 - 350 MCM #14 - 1/0 #14 - 1/0
460/60/3 #6 - 350 MCM #14 - 1/0 #14 - 1/0 #6 - 350 MCM #14 - 1/0 #14 - 1/0
575/60/3 #6 - 350 MCM #14 - 1/0 n/a #6 - 350 MCM #14 - 1/0 n/a
26
208/60/3 #6 - 350 MCM #6 - 350 MCM #6 - 350 MCM #6 - 350 MCM #6 - 350 MCM #6 - 350 MCM
230/60/3 #6 - 350 MCM #6 - 350 MCM #6 - 350 MCM #6 - 350 MCM #6 - 350 MCM #6 - 350 MCM
380/60/3 #6 - 350 MCM #14 - 1/0 #14 - 1/0 n/a n/a n/a
460/60/3 #6 - 350 MCM #14 - 1/0 #14 - 1/0 #6 - 350 MCM #14 - 1/0 #14 - 1/0
575/60/3 #6 - 350 MCM #14 - 1/0 n/a #6 - 350 MCM #14 - 1/0 n/a
30
208/60/3 #6 - 350 MCM #6 - 350 MCM #6 - 350 MCM #6 - 350 MCM #6 - 350 MCM #6 - 350 MCM
230/60/3 #6 - 350 MCM #6 - 350 MCM #6 - 350 MCM #6 - 350 MCM #6 - 350 MCM #6 - 350 MCM
380/60/3 #6 - 350 MCM #14 - 1/0 #14 - 1/0 n/a n/a n/a
460/60/3 #6 - 350 MCM #14 - 1/0 #14 - 1/0 #6 - 350 MCM #14 - 1/0 #14 - 1/0
575/60/3 #6 - 350 MCM #14 - 1/0 n/a #6 - 350 MCM #14 - 1/0 n/a
35
208/60/3 #6 - 350 MCM #6 - 350 MCM #6 - 350 MCM #6 - 350 MCM #6 - 350 MCM #6 - 350 MCM
230/60/3 #6 - 350 MCM #6 - 350 MCM #6 - 350 MCM #6 - 350 MCM #6 - 350 MCM #6 - 350 MCM
380/60/3 #6 - 350 MCM #14 - 1/0 #14 - 1/0 n/a n/a n/a
460/60/3 #6 - 350 MCM #14 - 1/0 #14 - 1/0 #6 - 350 MCM #14 - 1/0 #14 - 1/0
575/60/3 #6 - 350 MCM #14 - 1/0 n/a #6 - 350 MCM #14 - 1/0 n/a
40
208/60/3 #4 - 500 MCM 3/0 - 500 MCM² 3/0 - 500 MCM² #4 - 500 MCM 3/0 - 500 MCM² 3/0 - 500 MCM²
230/60/3 #4 - 500 MCM 3/0 - 500 MCM² 3/0 - 500 MCM² #4 - 500 MCM 3/0 - 500 MCM² 3/0 - 500 MCM²
380/60/3 #4 - 500 MCM #6 - 350 MCM #6 - 350 MCM n/a n/a n/a
460/60/3 #4 - 500 MCM #6 - 350 MCM #6 - 350 MCM #4 - 500 MCM #6 - 350 MCM #6 - 350 MCM
575/60/3 #4 - 500 MCM #6 - 350 MCM n/a #4 - 500 MCM #6 - 350 MCM n/a
52
208/60/3 #4 - 500 MCM 3/0 - 500 MCM² 3/0 - 500 MCM² #4 - 500 MCM 3/0 - 500 MCM² 3/0 - 500 MCM²
230/60/3 #4 - 500 MCM 3/0 - 500 MCM² 3/0 - 500 MCM² #4 - 500 MCM 3/0 - 500 MCM² 3/0 - 500 MCM²
380/60/3 #4 - 500 MCM #6 - 350 MCM #6 - 350 MCM n/a
460/60/3 #4 - 500 MCM #6 - 350 MCM #6 - 350 MCM #4 - 500 MCM #6 - 350 MCM #6 - 350 MCM
575/60/3 #4 - 500 MCM #6 - 350 MCM n/a #4 - 500 MCM #6 - 350 MCM n/a
60
208/60/3 #4 - 500 MCM 3/0 - 500 MCM² 3/0 - 500 MCM²
n/a230/60/3 #4 - 500 MCM 3/0 - 500 MCM² 3/0 - 500 MCM²
380/60/3 #4 - 500 MCM #6 - 350 MCM #6 - 350 MCM
460/60/3 #4 - 500 MCM #6 - 350 MCM #6 - 350 MCM #4 - 500 MCM #6 - 350 MCM #6 - 350 MCM
575/60/3 #4 - 500 MCM #6 - 350 MCM n/a #4 - 500 MCM #6 - 350 MCM n/a
1. Optional circuit breaker and high fault circuit breaker.
2. Will accept two conduits per phase in this size.
3. Copper wire only, based on nameplate Minimum Circuit Ampacity (MCA).
4. Data shown for circuit one. The second circuit is always the same.
5. n/a - not available
