162
RT-SVX24Q-EN
Table 56. Standard units with ERW — field measured plenum pressure — Low CFM ERW — 90-162 Tons (continued)
51000 — — — — — — — — — — — — 2.77 2.69 2.54 2.31 2 1.69 1.4 —
54000 — — — — — — — — — — — — 3.16 3.06 2.89 2.64 2.29 1.94 1.61 —
130-162 Ton Low CFM ERW - Field measured plenum pressure (inches wc)
CFM
OA Actuator Reading [Degrees] RA Actuator Reading [Degrees]
60 50 40 30 20 10 0 10 20 30 35 40 45
Econ
Traq
Econ
Traq
Econ
Traq
Econ
Traq
Econ
Traq
Econ
Traq
E/T E/T E/T E/T E/T E/T E/T
23000 1.82 — 1.27 — 1.06 1.27 0.96 1.05 0.91 1.02 0.89 0.87 0.67 0.65 0.62 0.57 0.51 0.44 0.39
26000 2.31 — 1.6 — 1.33 1.6 1.21 1.32 1.14 1.28 1.11 1.09 0.83 0.81 0.77 0.71 0.63 0.54 0.47
30000 — — 2.1 — 1.74 2.09 1.57 1.71 1.49 1.67 1.44 1.41 1.06 1.03 0.98 0.9 0.79 0.69 0.59
35000 — — 2.8 — 2.32 2.79 2.09 2.28 1.97 2.22 1.91 1.87 1.39 1.36 1.29 1.18 1.03 0.88 0.75
40000 — — — — 2.97 — 2.68 2.92 2.52 2.84 2.45 2.39 1.77 1.72 1.62 1.48 1.29 1.1 0.92
45000 — — — — — — — — — — — 2.96 2.17 2.11 1.99 1.81 1.57 1.33 1.1
50000 — — — — — — — — — — — — 2.62 2.54 2.39 2.17 1.87 1.57 1.3
55000 — — — — — — — — — — — — 3.09 3 2.82 2.56 2.2 1.83 1.5
58000 — — — — — — — — — — — — 3.4 3.29 3.1 2.8 2.4 1.99 1.62
UUnniitt SSttaarrttuupp
