Trane IntelliPak 2 Series User Manual

RT-SVX24Q-EN
91
Table 44. GBAS voltage vs. setpoint (continued)
Setpoint
GBAS 0-5 VDC GBAS 0-10 VDC
Valid Range
Unocc Zone Heating Setpoint
0.5 to 4.5 VDC 0.5 to 9.5 VDC 50 to 90°F
SA Cooling Setpoint (VAV only)
0.5 to 4.5 VDC 0.5 to 9.5 VDC 40 to 90°F
SA Cooling Setpoint (SZVAV only)
0.5 to 4.5 VDC 0.5 to 9.5 VDC 40 to 70°F
Zone Cooling Setpoint (SZVAV only)
0.5 to 4.5 VDC 0.5 to 9.5 VDC 50 to 80°F
Zone/Return Critical Temperature Setpoint (RR only)
0.5 to 4.5 VDC 0.5 to 9.5 VDC 75 to 95°F
SA Heating Setpoint (VAV only)
0.5 to 4.5 VDC 0.5 to 9.5 VDC 40 to 180°F
SA Heating Setpoint (SZVAV only)
0.5 to 4.5 VDC 0.5 to 9.5 VDC 65 to 95°F
Space Static Pressure Setpoint
0.5 to 4.5 VDC 0.5 to 9.5 VDC -0.20 to 0.30 IWC
SA Static Pressure Setpoint
0.5 to 4.5 VDC 0.5 to 9.5 VDC 0.7 to 5.1 IWC
Min OA Flow Setpoint 1
0.5 to 4.5 VDC 0.5 to 9.5 VDC 0 to Unit Max Flow
MWU Setpoint
0.5 to 4.5 VDC 0.5 to 9.5 VDC 50 to 90°F
Econ Dry Bulb Enable Setpoint
0.5 to 4.5 VDC 0.5 to 9.5 VDC 50 to 140°F
SA_Reheat_Setpoint
0.5 to 4.5 VDC 0.5 to 9.5 VDC 60 to 90°F
Minimum Position Setpoint 3
0.5 to 4.5 VDC 0.5 to 9.5 VDC 0 to 100%
Occ Dehumidification Setpoint
0.5 to 4.5 VDC 0.5 to 9.5 VDC 40 to 65%
Unocc Dehumidification Setpoint
0.5 to 4.5 VDC 0.5 to 9.5 VDC 40 to 65%
Occ Humidification Setpoint
0.5 to 4.5 VDC 0.5 to 9.5 VDC 20 to 50%
Unocc Humidification Setpoint
0.5 to 4.5 VDC 0.5 to 9.5 VDC 20 to 50%
Notes:
1. If DCV is enabled this is used for Design Minimum OA Flow Setpoint
2. If DCV is enabled, this is used for Design Minimum OA Damper Position Setpoint
Table 45. GBAS 0-10 VDC output range
Setpoint
GBAS 0-10 VDC
Valid Range
Outdoor Air Temperature
0.5 to 9.5 VDC -40 to 200°F
Zone Temperature
0.5 to 9.5 VDC -40 to 200°F
Supply Air Temperature (VAV only)
0.5 to 9.5 VDC -40 to 200°F
Supply Air Pressure (VAV only)
0.5 to 9.5 VDC 0.0 to 7.91 wc
Space Pressure
0.5 to 9.5 VDC -0.67-0.67 wc
Space RH
0.5 to 9.5 VDC 0-100%
OA RH 0.5 to 9.5 VDC 0-100%
Space CO
2
Level
0.5 to 9.5 VDC 50-2000 PPM
Cooling Capacity %
0.5 to 9.5 VDC 0-100%
Heating Capacity %
0.5 to 9.5 VDC 0-100%
Outdoor Air Damper Position
0.5 to 9.5 VDC 0-100%
Outdoor Airflow 0.5 to 9.5 VDC
0 to 65,000 CFM
IInnssttaallllaattiioonn
