Trane Sintesis RTAF User Manual

General Information
10 RTAF-SVX001A-EN
General Data
Table 1. General data table
Unit Size (tons) 115 130 150 170 180 200 215
Compressor Model (ckt1/ckt 2)
(a)
55/55 65/65 70/70 85/70 85/85 100/85 100/100
Quantity # 2222222
Evaporator
Water Connection Size in 4455566
2-Pass
Water Storage gal 14.0 15.8 19.3 20.6 21.6 21.9 23.9
L 53.1 59.9 73.2 78.0 81.9 82.8 90.5
Minimum Flow gpm 128 150 171 187 199 202 228
l/s 8.1 9.5 10.8 11.8 12.6 12.8 14.4
Maximum Flow gpm 470 551 626 684 731 742 835
l/s 29.7 34.8 39.5 43.2 46.1 46.8 52.7
Condenser
Qty of Coils (ckt 1/ckt 2) 5/5 5/5 6/6 6/6 6/6 7/7 7/7
Coil Length in 77.4 77.4 77.4 77.4 77.4 77.4 77.4
mm 1967 1967 1967 1967 1967 1967 1967
Coil Height in 47.8 47.8 47.8 47.8 47.8 47.8 47.8
mm 1214 1214 1214 1214 1214 1214 1214
Condenser Fans
Quantity (ckt 1/ckt 2) # 5/5 5/5 6/6 6/6 6/6 7/7 7/7
Diameter in 31.5 31.5 31.5 31.5 31.5 31.5 31.5
mm 800 800 800 800 800 800 800
Nominal speed rpm 810 810 810 810 810 909 909
Airflow cfm 9959 9959 9959 9959 9959 11230 11230
m3/s 4.7 4.7 4.7 4.7 4.7 5.3 5.3
Tip Speed ft/min 6673 6673 6673 6673 6673 7500 7500
m/s 33.9 33.9 33.9 33.9 33.9 38.1 38.1
Ambient Temperature Range
Standard Ambient °F (°C) 14 to 115 (-10 to 46)
Low Ambient °F (°C) -4 to 115 (-20 to 46)
High Ambient °F (°C) 14 to 130 (-10 to 54.4)
Wide Ambient °F (°C) -4 to 130 (-20 to 54.4)
General Unit
Refrigerant R-134a or R-513A
Refrigerant Ckts # 2222222
Minimum Load % 15 15 15 15 15 15 15
Refrigerant Charge (ckt 1/ckt 2) lb
86.4/
84.9
86.6/
84.9
101.4/
99.0
111.1/
99.0
109.0/
96.3
134.3/129.4 134.7/129.8
kg 39.2/38.5 39.3/38.5 46.0/44.9 50.4/44.9 49.5/43.7 60.9/58.7 61.1/59.0
Oil Trane Oil 00311 (bulk)/OIL00315 (1 gal)/OIL00317 (5 gal)
Oil Charge/ckt gal 1.53 1.56 1.56 1.56 1.64 1.96 2.01
L 5.8 5.9 5.9 5.9 6.2 7.4 7.6
(a) Nominal tonnage at 60 Hz.
