Trane Sintesis RTAF - Running (Lag Compressor;Circuit Start and Run)

Start-Up and Shutdown
56 RTAF-SVX001A-EN
Running (Lag Compressor/Circuit Start and Run)
Figure 47 shows a typical start and run sequence for the
lag compressor and its circuit.
Figure 47. Sequence of operation: running (lag compressor/circuit start nd run)
