Trane Sintesis RTAF - Page 17

Installation Mechanical
RTAF-SVX001A-EN 17
Table 7. Point weights
Location
12345678
Tons lb kg lb kg lb kg lb kg lb kg lb kg lb kg lb kg
115 1567 711 1601 726 1496 678 1530 694 937 425 960 435 - - - -
130 1589 721 1623 736 1517 688 1551 704 951 431 973 442 - - - -
150 2342 1062 2386 1082 1420 644 1445 656 1009 457 1025 465 - - - -
170 2294 1041 2332 1058 1557 706 1586 719 940 427 959 435 - - - -
180 2169 984 2658 1206 1621 735 1489 675 1077 488 989 449 - - - -
200 2189 993 2162 974 1734 787 1702 772 923 419 907 411 711 322 699 317
215 2303 1045 2159 979 1761 799 1653 750 901 409 1271 576 673 305 634 287
Table 8. Isolator selections
Location
Tons 1 2345678
115 Red 62 Red 62 Red 62 Red 62 Black 61 Black 61 - -
130 Red 62 Red 62 Red 62 Red 62 Black 61 Black 61 - -
150 Gray 64 Gray 64 Red 62 Red 62 Black 61 Black 61 - -
170 Gray 64 Gray 64 Red 62 Red 62 Black 61 Black 61 - -
180 Gray 64 Gray 64 Red 62 Red 62 Black 61 Black 61 - -
200 Gray 64 Gray 64 Gray 64 Gray 64 Red 62 Red 62 Black 61 Black 61
215 Gray 64 Gray 64 Gray 64 Gray 64 Red 62 Red 62 Black 61 Black 61
