Trane Sintesis RTAF - Page 22

Installation Mechanical
22 RTAF-SVX001A-EN
Figure 12. Evaporator water pressure drop — 2-pass with turbulators
0.0
8.0
16.0
24.0
32.0
40.0
48.0
56.0
64.0
72.0
80.0
88.0
0 100 200 300 400 500 600 700 800 900 1000
Pressure Drop (ft. H2O)
Water Flow (GPM)
215T
200T
180T
170T
150T
130T
115T
