Trane UniTrane Fan-Coil User Manual

Dimensions and Weights
24 UNT-SVX07E-EN
Model D Horizontal Cabinet
Figure 8. Model D Horizontal Cabinet
Top View
E
Back inlet duct collar
8 in. 8 in.
J
Back and bottom
inlet louvers
Optional
disconnect
switch
Aux
box
Control
box
(4) 5/8 in. dia keyslot
hanger holes
Secondary drain
connection for
3/8 in. ID tube
Main drain connection
for 7/8 in. OD copper
tube and clamp
15 1/2 in.
7/8 in.
KO control
wiring
(2) 5/8 in.
bolt holes
Front View
RH Piping
Unit control
front
Front outlet
duct collar (optional)
H
B
G
6 in.
G
6 in.
3 3/4 in.
13 3/4 in.
3 3/4 in.
1 5/8 in.
Front outlet
quadrifuser or bar grille
C
D
C
A
8 in.
F Optional extended end pocket
2 7/8 in.
1 3/8 in.
Aux box opt.
6 1/4 in.
Control box
1 3/32 in.
KO
7/8 in. KO
Power
wiring
bottom
only
Front View
LH Piping
Coil connections
1 1/8 in.
Aux Box
optional
Control boxAuxiliary
drain pan
Filters
2 1/4 in.
Bottom inlet
louvers
7 5/16 in.
1 in. duct
collar
Side View
Inlet and outlet
options
1 3/4 in.
7 in.
Filters
Back inlet
duct collar
1 in. front outlet
duct collar
27 13/16 in.
26 13/16 in.
1 3/4 in.
7 in.
10 5/16 in.
Back inlet
louvers
Bottom access panel - all units
90° to fully open
8 7/8 in.
3 5/8 in.
4 in.
Air
flow
Filters
