Dimensions and Weights
40 UNT-SVX07E-EN
Model N Inverted Vertical Recessed
Force-Flo Unit Only
Front View
LH Piping
Front View
RH Piping
Side
View
Top View
C
1 3/4 in.
1 3/4 in.
(4) 5/8 in. dia keyslot
hanger holes
5 1/2 in.
6 5/8 in.
Power
wiring
bottom
only
7/8 in. KO
1 3/32 in.
KO
2 5/16 in.
4 9/16 in.
3/4 in.
1 3/4 in.
Optional
disconnect
switch
3/4 in.
1 3/4 in.
6 5/8 in.
5/8 in. 9 3/4 in.
B
F
Front
panel
G
Wall
opening
15 1/2 in.
2 1/8 in.
(4) 5/8 in. dia
keyslot hander holes
1 in.
Front outlet louvers
Control
box
7/8 in. KO
control
wiring
6 15/16 in.
A
H Wall opening
E Front panel
7 in.
4 15/16 in.
Filters
Coil
connections
4 15/16 in.
15 3/8 in.
1 1/8 in.
1 in. Wall opening
Control
box
Front
control
access
(optional)
25 1/4 in.
Air
flow
