Dimensions and Weights
UNT-SVX07E-EN 45
Force Flo Vertical Units
Figure 18. Coil connections for Force Flo cabinet heater vertical units
5 5/16 in. HS
4 3/8 in. HR
5 5/16 in. HS
4 3/8 in. HR
5 3/8 in. HS
4 7/16 in. HR
5 5/16 in. HS
4 3/8 in. HR
23 3/8 in.
HS
22 3/8 in.
HR
20 13/16 in.
HR
21 13/16 in.
HS
HS
HR
HS
HR
HS
HR
HS
HR
Vertical Concealed
Vertical Recessed
(recess panel not shown)
Vertical Cabinet Vertical Slope
Top Cabinet
Vertical Wall
Hung Cabinet
Bottom of
Vertical Units
