1.5 Charging
• Power supply
The charging process is the same for rack battery packs (39-cell and 30-cell) and battery packs
mountedonthedowntube(39-cell/52-cell).Allbatterypackscanbechargedusingthepower
supply, on the bike or removed from the bike.
RIDE+ R250 RIDE+ R320
RIDE+ R320 RIDE+ C320 and RIDE+ C420
Attention. When not in use, charge a battery pack at least once every 3 months.
• Charging the battery pack
1. Turn the system off.
2. Connect the connector of the power supply to the charging port of
the battery pack and connect the power supply to the power outlet.
Warning. Replace a damaged power cable immediately to prevent an electric shock.
3. The battery pack will emit beeps and then the charging port will turn
orange. When the battery pack is full, the charging port will turn green.
To stop charging, just disconnect both connectors.
