Management VLAN
This feature is only available under Access Point or WDS AP mode and
allows users to configure the 802.1q VLAN settings to for all wireless
clients. Enter VLAN ID you want to tag to clients associated with specific
SSID. Different SSID should set to different VLAN ID. Enable Virtual LAN
service and click Apply to save the changes.
LAN VLAN MGMT is a special VLAN to manage TEW-735AP. Enabling
management VLAN tagging will keep all services, for example DHCP
server and client, in this VLAN.
Virtual LAN:
Choose to Enable or Disable the VLAN
features.
SSID 1 - 4
Tag:
Enter VLAN tag you want to add for associated
clients. Check the leading check box to enable
tagging. All SSIDs have to have different VLAN
tag. Valid settings are between 1 and 4094.
LAN VLAN
MGMT:
Enable or disable TEW-735AP services on a
specific VLAN. If management VLAN tagging is
enabled, all service packets, including web
management, DHCP server/ client, will be
tagged with a specified tag.
MGMT Tag:
VLAN number for TEW-735AP services. This
number has to be different from all above
VLAN numbers.
Apply: Click this button to save and activate
Cancel: Click this button to abandon the change

TRENDnet TEW-735AP Specifications

General

Modulation	-
Frequency band	2.4 GHz
Number of users	- user(s)
Channels quantity	- channels
Networking standards	IEEE 802.11az, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3af, IEEE 802.3u, IEEE 802.3x
Ethernet LAN data rates	10, 100 Mbit/s
Maximum data transfer rate	300 Mbit/s
Internal	No
Certification	CE, FCC
WAN connection	Ethernet (RJ-45)
Security algorithms	WPA2
Operating temperature (T-T)	0 - 45 °C
Power supply	12 W
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Cables included	LAN (RJ-45)
Antenna features	Integrated antenna
Antennas quantity	2
Antenna gain level (max)	4 dBi

Weight and Dimensions

Depth	60 mm
Width	128 mm
Weight	210 g
