“LIVELINK INSTALL” APP / ROOM ADMINISTRATION / ROOM SETUP: OPTION “ADMINISTRATE SCENES” Page 51 / 77
ROOM SETUP:
OPTION “ADMINISTRATE SCENES”
In this view, light scenes are administrated and set up.
Typical scenes are included in the Use Case delivery. Additional scenes can
be created completely from scratch or duplicated from existing scenes. Of
course, all configuration options are available in either case.
A light scene consists of dimming settings of the individual luminaire groups
as well as sensor options. Depending on the equipment, the sensors can be
utilised for presence detection and/or constant light control. Different sensor
settings are available for both modes of operation.
New scenes can be created and configured
by tapping the plus symbol.
The dimming value of the individual
groups is specified in percent.
A group is activated by tapping it and
the value can be configured.
Provides access to the
sensor options.
Selecting predefined scenes. Prede-
fined scenes contain typical settings
for light situations. The default scene is
marked with this dot, for the behaviour
e.g. upon switching mains power on.
Control wheel for the setting of
the dimming values of the lu-
minaire groups or of the control
parameters of the sensors.
1.
Creating the illumination
settings of a scene
2.
Setting the sensor system
of a scene
