Trilux LiveLink User Manual

“LIVELINK INSTALL” APP / ROOM ADMINISTRATION / ROOM SETUP: OPTION “SETTING UP SCENES” Page 54 / 77
ROOM SETUP: OPTION “SETTING UP SCENES”
In this view, dimming values as well as sensor options can be adjusted now.
Selecting luminaire groups
A luminaire group is activated by tapping on it; an
active luminaire group is shown in red.
Multiple luminaire groups can be activated one after
another in order to configure them at the same time.
Specifying the dimming value
The activated luminaire groups can be dimmed to
the desired level with the control wheel.

Trilux LiveLink Specifications

General

Type	Control Unit
Input Voltage	230V AC
Frequency	50/60 Hz
Protection Rating	IP20
Communication Protocols	DALI
Mounting Options	DIN rail
