“LIVELINK INSTALL” APP / ROOM ADMINISTRATION / ROOM SETUP: ASSIGNING PUSH-BUTTONS Page 44 / 77
ROOM SETUP: ASSIGNING PUSH-
BUTTONS
In this view, the push-buttons are connected to a light scene or a luminaire group
If a light scene is assigned to a push-button, this light scene is activated later upon
pushing the button.
If a luminaire is assigned to a push-button, the respective luminaire groups is
dimmed or switched later upon pushing the button (touch/dim function).
Only one single light scene can be assigned to a push-button. But not all push-
buttons and light scenes need to be linked.
New push-button assignments can be
created by tapping the plus symbol.
Selecting the light scene or luminaire
group, respectively.
Testing the scene
Subsequent to a long tap on a scene, it
can be activated for a test.
Choice between scenes and luminaire
groups.
A push-button either activates a light scene
or switches a luminaire group on or off,
respectively.
Listing all push-button assignments
set up.
Labelling the push-button assignment.
1.
Assigning push-buttons
