Trophy 1802 - Helm Views by Model

24
Chapter 3: Locations Walkaround Models • Owner’s Manual Supplement
Helm Views
1802
2002/2052
COMPASS
NAVIGATION LIGHTS
HORN
BILGE PUMP
TACHOMETER
ACCESSORY SWITCHES
INSTRUMENT LIGHTS
BAITWELL
FUEL GAUGE
VOLTMETER
SPEEDOMETER
IGNITION
SHIFT/THROTTLE LEVER
BAITWELL
STARBOARD FISH
LOCKER DRAIN
BILGE PUMP
WIPER
ACCESSORY SWITCHES
TRIM TAB SWITCHES
IGNITION 12 VOLT
RECEPTACLE
DC BREAKER
PANEL
THROTTLE/SHIFT
LEVER
HORN
PORT FISH
LOCKER DRAIN
COCKPIT LIGHTS
NAVIGATION LIGHTS
ANCHOR LIGHT
COMPASS
TACHOMETERSPEEDOMETER
FUEL GAUGE
& VOLTMETER
TEMP GAUGE
& OIL GAUGE
ACCESSORY SWITCH
BLOWER
(2052 ONLY)
