86
Chapter 12: Electrical System Walkaround Models • Owner’s Manual Supplement
Hull Electrical Harness Views
1802
2002
BILGE PUMP
BILGE HARNESS
PLUG
FUEL TANK
SENDER
BILGE HARNESS
PLUG
BAITWELL
PUMP
BILGE PUMP
FUEL TANK
SENDER
