Walkaround Models • Owner’s Manual Supplement
Chapter 10: Convertible Seats, Beds, & Tables
Dinette/V-Berth
2002/2052 Conversion
The dinette table can be removed and the dinette area can be converted into a berth.
1. Lift the table (A) and remove the table leg (B).
2. Place the table (A) so that it fits securely on the edge lips (C) at the front of the dinette seats.
3. Unfold the hinged filler boards (D) and place them securely on the edge lips (C) at the front of the dinette seats.
4. Place the filler cushions (E) on top of the filler boards.
A
B
C
D
E
A
