Trophy 1802 - Marine Head System

49
Walkaround Models • Owner’s Manual Supplement Chapter 7: Plumbing
Marine Head with Holding Tank (If Equipped)
2302/2352 Marine Head System
2502 Marine Head System
Check with local authorities for regulations regarding the legal use of marine head systems.
NOTICE
HEAD
HOLDING TANK
VENT HOSE
WASTE PUMP-OUT
DECK FITTING
MACERATOR
(IF EQUIPPED)
HOLDING TANK
OVERBOARD
DISCHARGE
SEACOCK
SEAWATER
PICKUP
SEACOCK
SEAWATER
PICKUP
SEACOCK
OVERBOARD
DISCHARGE
SEACOCK
HOLDING TANK
HEAD
WASTE PUMP-OUT
DECK FITTING
MACERATOR
(IF EQUIPPED)
HOLDING TANK
VENT HOSE
